Rotation Portion:
Double American Eatonbrand hydraulic motor,supplying high torque,Max 6000N.m , it Can achieve 0-120RPM stepless speed regulation
Lifting Portion
Forwarding power and Lifting power is big.Lifting chain with high quality roller chain,safe and reliable.
Power:
High pressure oil pump original import form American or Italia,Supplying strong power for hydraulic systerm
| Model | TZ-458B |
| Max Hole diameter (mm) | 254mm |
| Max Drill depth (m) | 40m |
| Walking speed (km/h) | 2.5km/h |
| Gradeability | 25° |
| Max Rotary torque | 3600/4500/6000N.m |
| Lifting power | 2T |
| Drill rod length | 3M |
| Forwarding length | 4.1M |
| Sliding frameworks wing angle | right:45,left:15 |
| Drill hand swing angle | right/left:45 |
| Max horizontal drilling height | 3.6M |
| Working Pressure (Mpa) | 1-3Mpa |
| Air consumption (M3/min) | 10-30m³/min |
| Engine power(KW) | 75Kw |
| Weight | 6800kg |
| L x W x H | 6700×2200×2750 |
