600m Reverse Circulation drilling rig
Good Quality
Good Price
Good After Service
Good solutions
Description
| Model | TZ-600 RC | |||
| Max dritling depth (m) | 600 | |||
| Drilling diameter (mm) | 105-450 | |||
| Air pressure (Bar) | 1.6-6 | |||
| Air consumotion (m3/min) | 16-75 | |||
| Drill Pipe Length (m) | 3 | |||
| Recommend Drill Pipe | 102 | |||
| Main shaft pressure (T) | 7 | |||
| Lifting force (T) | 28 | |||
| Fast lifting speed (m/min) | 29 | |||
| Fast forwarding speed | 28 | |||
| Rotary torque (Nm) | 12000/6000 | |||
| Rotary speed (R/min) | 93/186 | |||
| Winch liftting force (T) | 1.5 | |||
| Leg Stroke (m) | 1.6 | |||
| Drilling efficiency (m/h) | 10-35 | |||
| Drilling angle (°) | 40-90 | |||
| Walking Speed (Km/h) | 3 | |||
| Grade ability (°) | 21 | |||
| Dimension（m） | 7.9×2.25×3.1 | |||
| Weight （T） | 12 | |||
